　　1, according to the diameter of reel making school circle model, the arc length of the pipe circumference of 1/6 ~ 1/4, do not fit the gap to meet the requirements.

　　2、管子、管件组对时，应检查坡口质量。并对坡口内外侧进行清理，有锈垢可采用砂轮机磨光。

　　2. The quality of the groove shall be checked when the pipe and pipe fittings are in alignment. And cleaning the inside and outside sides of the groove. There is rust and can be polished by sanding machine.

　　3、核对材料和规格是否符合设计要求，材质证明和合格证是否齐全，有开裂缩孔、起皱、分层等缺陷，应拒绝使用。

　　3, check the material and specifications are in line with the design requirements, materials and certificates are complete, there are cracks, shrinkage, wrinkling, delamination and other defects, should be refused to use.

　　4、焊条要求：焊接碳素钢的焊条采用E4303焊条，焊接16Mn钢板的焊条采用E5016焊条。当16Mn钢与碳素钢接缝处E4316焊条。焊条使用之前，应按说明书进行烘干，并在使用中保持干燥，焊条药皮应无脱落和明显裂纹。

　　4, welding rod requirements: welding carbon steel welding rod using E4303 welding rod, welding 16Mn steel plate welding electrode, using E5016 welding rod. When 16Mn steel and carbon steel joint, E4316 welding rod. Before welding the electrode, it should be dried according to the instruction manual and kept dry in use. The electrode coating should be free of cracks and obvious cracks.

　　6、先做压头处理，再进行卷制。

　　6, the first pressure head treatment, and then roll system.

　　7、正式施工焊的材料焊接工艺相同。

　　7, the formal construction of welding materials, welding process is the same.

　　8、壁厚不同的管子对焊时，两管壁厚之差不得大于管壁厚度的15%，并不得超过3mm。

　　8. When the wall thickness is different, the difference between the wall thickness of the two pipe shall not exceed 15% of the thickness of the pipe wall and shall not exceed 3mm.

　　9、不同直径的管子对焊时，可将大管焊接端抽条加工成大小头，也可采用钢板制作大小头。

　　9, different diameter of the pipe butt welding, can be welded to the end of the big pipe processing into big head, also can use steel plate making big head.
