酒店厨房排烟罩设计安装方法

来源:http://www.jnqsg.com/     发布时间:2022-09-02

酒店厨房排烟罩设计安装方法是怎样的呢?为了更好的使用排烟罩进行日产生活或者工作,就应该对此有一个充足的了解,下面济南排烟罩厂家为您讲讲这个问题。
What is the design and installation method of smoke exhaust hood in hotel kitchen? In order to better use the smoke hood for daily life or work, you should have a sufficient understanding of this. The following Jinan smoke hood manufacturer will tell you about this problem.
1、厨房排烟罩安装的墙体,它的构造和材料都应该要有足够的强度。排烟管、风管的外墙开口,可采用砌筑预制带洞混凝土块或预埋钢管留洞方式。保温墙(好要用空心砖)与正常墙壁的安装方法一样,如果墙面不够结实的话,那么就要用木板或其他材料进行加固。
1. The structure and material of the wall where the kitchen smoke hood is installed should have sufficient strength. The external wall openings of smoke exhaust pipes and air ducts can be built with precast concrete blocks with holes or embedded steel pipes. The installation method of thermal insulation wall (good hollow brick) is the same as that of normal wall. If the wall is not strong enough, it should be reinforced with wood or other materials.
2、厨房排烟罩安装的烟管直接穿过外墙室外,应该在室外排气口设置防止污染环境和避风的构件。共用竖向烟道连接的吸油烟机,它的竖向烟道的断面应根据所负担的排气量计算确定。
2. The smoke pipe installed in the kitchen smoke exhaust hood directly passes through the outer wall to the outside, and the outdoor exhaust outlet shall be provided with components to prevent environmental pollution and avoid wind. For the range hood connected by the common vertical flue, the cross-section of its vertical flue shall be determined according to the exhaust volume.
3、厨房排烟罩安装顶吸式的安装高度应该在燃气炉灶上方少65厘米的地方,在65-75厘米之间是比较合适的。
3. The installation height of the top suction type of the kitchen smoke hood should be at least 65cm above the gas stove, and it is more appropriate to install it between 65-75cm.
济南排烟罩
在顶棚里面预埋直径160MM的PCV管,放在烟机设计位置的上方。在吊柜顶部与厨房顶棚之间的空隙走,吊柜前面需要设计封板遮挡。在烟机二层挡板后面直接走背墙,这样的一半是别墅才能实现。
A PCV pipe with a diameter of 160mm is embedded in the ceiling and placed above the design position of the smoke machine. Walk in the gap between the top of the hanging cabinet and the kitchen ceiling, and the front of the hanging cabinet needs to be covered by a sealing plate. Go directly behind the baffle on the second floor of the smoke machine to the back wall, which can only be realized by villas.
老式房子,没用公用烟道的,烟机在飘窗上,烟机管走窗户玻璃。厨房高度吊顶后低于2300,种第二种方法无法实现,烟机管在吊柜里穿过吊柜侧板进入共用烟道烟机烟道的的设计直接影响到烟机的排烟效果和整体厨房外观的效果,建议采用、第二种方式。
In old-fashioned houses, there is no common flue. The smoke machine is on the window, and the smoke tube is on the window glass. The height of the kitchen is lower than 2300 after the ceiling. The first and second methods can not be realized. The flue gas pipe passes through the side plate of the hanging cabinet in the hanging cabinet and enters the common flue. The design of the flue gas duct directly affects the smoke exhaust effect of the flue gas machine and the overall appearance of the kitchen. It is recommended to adopt the first and second methods.
这就是今天小编为您带来的资讯,如果你还想知道更多关于排烟罩方面的知识,请关注我们的网站http://www.jnqsg.com,为您提供新资讯!
This is the information that Xiaobian brought to you today. If you still want to know more about smoke hoods, please follow our website http://www.jnqsg.com , to provide you with new information!
