　　机壳由顶壳、侧板(两块)、集油罩组成，均采用冷轧薄钢板并经烤漆制成，或采用表面经喷塑、搪瓷处理，也有用不锈钢板制成，使外型光亮美观、耐用易于清洁。

　　The shell from the top and side shell (two), the oil collecting cover adopts cold rolled steel sheet and the paint is made, or the surface of the spray, enamel, made of stainless steel plates are also useful, so that the appearance of bright and beautiful, durable and easy to clean.

　　顶壳与侧板采用点焊技术焊接，使顶壳与侧板构成一个盆体结构，由它支承油烟净化器各个零部件，顶壳为双头风机公共出风口，出风口两侧有两个圆孔供安装电机用。

　　The top shell and side plates by welding spot welding technology, the top shell and side plates to form a basin body structure, which supports various parts of fume purifier, top shell central fan public double outlet, the outlet sides have two holes for installing motor.

　　集油罩也冲压成带翻边的盆体，与顶壳圆孔位置对称地冲出两个翻边圆孑L，供风机吸油烟用。集油罩的罩面尺寸比较大，有效地覆盖灶具面积，从而收集污染气体和油烟经风机、排烟管排出室外。

　　The oil collecting cover also punched into a basin body with a flange, and the top shell hole position symmetrically out the two round hole flanging L fan with oil smoke. The cover surface of the oil collecting hood is larger, and the range of the cooker is effectively covered, thereby collecting the pollution gas and soot, and discharging out of the air through the fan and the smoke exhaust pipe.

　　电动机是油烟净化器的核心部件，采用两台(单头油烟净化器采用一台)全封闭的单相220V电容运转式异步电动机，功率为30～IOOW。

　　The motor is the core component of the soot purifier. It uses two units (a single head lampblack purifier with one) and a single enclosed 220V capacitor operated asynchronous motor with power of 30 ~ IOOW.

　　电机主要由前、后壳、定子、转子构成，分别安装在顶壳的两个圆形的塑料法兰中，电动机后壳安装了一个后盖，起防尘作用。

　　The motor is mainly composed of front, back shell, stator and rotor. They are respectively installed in the two round plastic flanges of the top shell, and the back shell of the motor is equipped with a back cover to prevent dust.

　　外排式油烟净化器使用的电动机结构简单，启动性能好，转矩大，噪声低，运转平稳。由于电动机长期在油烟和水蒸气环境中使用，所以对电机的要求特别高，而采用绝缘性能、防潮、防腐蚀性能好的全封闭式电动机。

　　The motor used for the platoon lampblack purifier has the advantages of simple structure, good starting performance, large torque, low noise and stable operation. As the motor has been used in the smoke and water environment for a long time, the requirements of the motor are particularly high, and the whole enclosed motor with good insulation, moisture resistance and corrosion resistance is adopted.
