Kitchen equipment smoke exhaust hoods are generally processed as a whole, including filtration, oil collection, water collection and other equipment, and are mostly produced by professional companies. Its appearance should be uniform, beautiful, and easy to clean. In kitchen ventilation, a certain amount of fresh air needs to be added. On the one hand, it can balance the air pressure and avoid excessive negative pressure in the kitchen (generally not exceeding 5Pa), and on the other hand, it can reduce the temperature inside the kitchen and improve the working environment. For the collection of cooking fumes, there are three main categories of gas collection (smoke) hoods used:

(1)简易不含挡油板和送风设备的集气罩适合各种灵活机动场所，便于加工安装，便宜。但由于没有送风设备，集风效果相对较差，容易使油烟在厨房工作人员面前回旋，并且容易造成油滴散落。

(1) The simple gas collection hood without oil baffles and air supply equipment is suitable for various flexible and mobile places, easy to process and install, and cheap in price. However, due to the lack of air supply equipment, the air collection effect is relatively poor, which can easily cause oil fumes to swirl in front of kitchen staff and cause oil droplets to scatter.

(2)含挡油板和送风设备的集气罩能够较好地收集烹饪过程产生的油烟，油滴不散落，只要送风风量合理，厨房操作人员工作面的空气质量就好。但安装要求较高，投资较大。

(2) The gas collection hood with oil baffle and air supply equipment can effectively collect oil fumes generated during the cooking process, and oil droplets do not scatter. As long as the air supply volume is reasonable, the air quality of the kitchen operator's working face is good. But the installation requirements are high and the investment is large.

(3)运水集气(烟)罩

(3) Water and gas collection (smoke) hood

运水集气(烟)罩的设计原理是形成水幕循环，与油烟碰撞后达到净化油烟的目的。影响运水集气(烟)罩使用效果的关键是要形成连续的水幕

The design principle of the water transportation and gas collection (smoke) hood is to form a water curtain circulation, which collides with the oil smoke to achieve the purpose of purifying the oil smoke. The key to affecting the effectiveness of water transportation and gas collection (smoke) hood is to form a continuous water curtain

而只是形成了断续流动的水滴或小水柱，因此使用效果非常差。

However, it only forms intermittent flowing water droplets or small water columns, so the use effect is very poor.

使用运水集气(烟)罩的优点是能够在集气(烟)罩处除掉部分油烟，减轻油烟净化设备的处理负荷，提高系统的净化效果。但如果运水集气(烟)罩的过烟缝隙较窄，容易引起排烟系统不通畅。

The advantage of using a water carrying gas (smoke) hood is that it can remove some oil smoke at the gas (smoke) hood, reduce the processing load of the oil smoke purification equipment, and improve the purification effect of the system. But if the smoke passage gap of the water collection (smoke) hood is narrow, it is easy to cause the smoke exhaust system to be blocked.

集气罩的设计对于排烟系统具有重要的影响。集气罩设计不合理就很容易造成整个排烟系统不畅。引起排烟系统不通畅的因素有：

The design of the gas collection hood has an important impact on the smoke exhaust system. Unreasonable design of the gas collection hood can easily cause the entire smoke exhaust system to malfunction. The factors that cause obstruction of the smoke exhaust system include:

1)油板间或者运水集气(烟)罩缝隙过小，这种情况较多

1) There are many cases where the gap between the oil plates or the water and gas collection (smoke) hood is too small

2)烟罩内收集油烟的开口总的截面积太小而引起整体排烟不通畅

2) The total cross-sectional area of the opening inside the hood for collecting oil fumes is too small, causing overall smoke exhaust to be obstructed

3)开口分布不合理或是开口没有随着与主管道的距离增大而增大，从而引起局部排烟不通畅

3) The distribution of openings is unreasonable or does not increase with the distance from the main pipeline, resulting in local smoke exhaust obstruction

4)集气(烟)罩上面的集烟管道截面积太小，导致出烟不通畅。

4) The cross-sectional area of the smoke collection pipeline above the gas (smoke) hood is too small, resulting in obstructed smoke discharge.
