油烟净化器的末端必需加装向下的90°弯头

来源:http://www.jnqsg.com/     发布时间:2017-11-14

  厨房内送、排风口的布置应按灶具的具体位置加以考虑,不要让送风射流扰乱灶具的排风性通。确定送风出口的入口风速时,送风口应沿排风罩方向布置,而排风口距排风罩越远越好。

  The arrangement of the air supply and exhaust outlets in the kitchen should be considered according to the specific location of the cooker, so that the ventilation of the cooker can not be disturbed by the air jet. When the inlet wind speed of the air supply outlet is determined, the air outlet shall be arranged along the direction of the exhaust hood, and the distance from the exhaust hood to the exhaust hood is better.

  山东通风管道加工安装油烟净化装置之前,要对排烟系统中各部分的实际运行参数,包括运行阻力和排风量进行核算。

  Before the installation of lampblack purification equipment for ventilation pipes in Shandong, it is necessary to calculate the actual operating parameters of the exhaust system, including the operation resistance and exhaust air volume.

  如果是新建项目,设计时要充分考虑装置了油烟净化器后对排风系统的影响;如果是改造项目,加装油烟净化器时需要对排风系统重新进行核算,必要时要对集烟罩、排烟管道和厨房整体补风装置进行改造并更换排烟风机。
山东通风管道加工

  If the new project design to fully consider the impact on the exhaust system for fume purifier; if installed fume purifier renovation project, need to re check the exhaust system, when necessary for collecting hood, exhaust pipe and air supply device of kitchen renovation and replacement of the exhaust fan.

  厨房排烟管道的水平段不宜太长,水平末端设活接头,以方便清理油垢。以防风速过低使油附着于烟道上, 如果在装油烟净化器之前,引风机已经装好无法挪动的情况下,建议选择将油烟净化器装在引风机的末端,但是前提:油烟净化器的末端必需加装向下的90°弯头,或者向上90°弯头加防雨帽,因为油烟净化器里面不能进水,里面的高压电场怕联电引起不必要的麻烦。

  The exhaust pipe of the horizontal section of the kitchen should not be too long, the level set the end of union, to facilitate the removal of grease. The wind speed is too low to make the oil attached to the flue, if installed before the fume purifier has been installed to move under the condition of fan, recommended to choose the end, lampblack purifier installed in the fan but the premise: the end of oil smoke purifier must be installed 90 degrees bend downward or upward, 90 degrees bend with the rain hat, because the oil fume purifier which can not be afraid of water, the high voltage electric field inside the UMC cause unnecessary trouble.

  以上便是山东通风管道加工今天的分享,您还满意吗,欢迎关注我们的网站:http://www.jnqsg.com/并且关注我们的产品,我们将为您提供的产品,衷心的愿与您建立合作关系。

  The above is Shandong ventilation pipe processing today's share, you are satisfied, welcome to pay attention to our website: http://www.jnqsg.com/ and pay attention to our products, we will provide you with good products, sincerely willing to establish a cooperative relationship with you.
