一.工艺要求
I. process requirements
1、装置风管前，应将图纸与施工现场进行核对，查看能否按规划的标高和方位进行装置；
1. Before installing the air duct, the drawings should be checked with the construction site to see if the installation can be carried out according to the planned elevation and orientation.
2、运用红外线定位放线，保证风管的间隔及直线度，并按风管的中心线，找出吊杆装置方位， 进行支吊架装置；
2. Use infrared positioning and setting-out to ensure the air pipe spacing and straightness, and according to the central line of the air pipe, find out the suspender device orientation, support and hanger device;
3、风管体系的各部分尺度和视点承认准确无误后，开端组对装置，风管的衔接应平直、不歪曲，且衔接法兰的螺母应在同一侧；
3. After the scale and viewpoint of each part of the air duct system are admitted to be accurate, the connection of the air duct should be straight and not distorted, and the nut of the connecting flange should be on the same side.
4、风管与风管法兰间的垫片选用厚3mm及以上的耐热橡胶板，垫片不该凸入管内，亦不宜杰出法兰，且垫片中不该含有石棉及其它有害成分，且应耐油耐潮耐酸碱腐蚀；
4. The gasket between the air duct and the air duct flange should be heat-resistant rubber plate with thickness of 3 mm or more. The gasket should not be protruded into the pipe or outstanding flange, and the gasket should not contain asbestos and other harmful components, and should be resistant to oil, moisture, acid and alkali corrosion.
5、风管装置时，有必要坚持风管中心线的水平，装置一段风管后运用水平尺丈量水平；风管长度超越20m时，有必要设置防晃支架，且每个体系不少于一副；
5. It is necessary to insist on the level of the central line of the air duct when installing the air duct, and measure the level with a horizontal ruler after installing the first section of the air duct.
6、在风管穿过需求关闭的防火、防爆的墙体或楼板时，应设预埋管或防护套管，其钢板厚度为2mm。风管与防护套管之间，应用不燃且对人体无损害的柔性资料封堵；
6. When the duct passes through the fire-proof or explosion-proof wall or floor that needs to be closed, it should be equipped with embedded pipes or protective sleeves with a steel plate thickness of 2 mm. Between the wind pipe and the protective sleeve, the flammable and flexible data without damage to the human body are used for plugging.
7、各类风管部件及操作组织的装置，先查看阀门外形及操作组织是否完好，查看动作的灵活性，承认阀门各方面正常之后再进行装置装置方向、方位应正确，在阀门操作组织一侧应少有350mm的净空间，以便操作、检修；防火分区隔墙两边的防火阀，间隔墙体外表不该大于200mm；
7. All kinds of air duct components and operation organization of the device, check the valve shape and operation organization is intact, check the flexibility of action, recognize the normal valve after all aspects of the device direction and orientation should be correct, in the valve operation organization side should have at least 350 mm of clean space for operation, inspection and repair; The fireproof valve on both sides of partition wall should not be larger than 200mm on the surface of the partition wall.
8、防火排烟风管的支吊架有必要独自设置，支管、管道式消声器、消声器弯头、防火阀有必要独自设置支、吊架；
8. It is necessary to install the support and hanger of the fire-proof smoke exhaust duct by itself, and the support and hanger of the branch, pipe muffler, muffler elbow and fire-proof valve by themselves.
9、风管装置结束后，应按体系压力等级进行严密性查验。
9, after the end of the wind pipe device, we should tighten the inspection according to the pressure level of the system.
二.质量操控关键
Two. Key to quality control
1、风管内禁止有杂物或其它管线穿越，并做好清洁和维护作业；
1. No debris or other pipeline crossing is allowed in the wind pipe, and cleaning and maintenance work should be done well.
2、支吊架下沿和外缘与接触网带电体(含承力索,下馈线等)间隔有必要坚持大于230mm,并应严厉依照限界要求施行；
2. It is necessary to insist that the safety interval between the lower edge and outer edge of the support hanger and the charged body of the catenary (including the load-bearing cable, the lower feeder line, etc.) be greater than 230mm, and it should be strictly carried out in accordance with the requirements of the limit.
3、衔接螺栓应为镀锌螺栓，一起有必要装备相应的平垫、弹垫和螺母；
3, the connecting bolts should be galvanized bolts, and it is necessary to equip corresponding flat pads, elastic pads and nuts.
4、风管法兰垫片的作业温度不小于70℃；关于排烟风管法兰垫片的作业温度要求不小于250℃；
4. The operating temperature of the air duct flange gasket shall not be less than 70, and the operating temperature of the air duct flange gasket shall not be less than 250.
5、风管装置的水平度答应误差每米不该大于3mm，总误差不该大于20mm；垂直装置垂直度的答应误差为每米不超越2mm，总误差不该大于 20mm；
5. The allowable horizontal error of the air duct device should not be greater than 3 mm per meter, the total error should not be greater than 20 mm; the allowable vertical error of the vertical device should not exceed 2 mm per meter, the total error should not be greater than 20 mm;
6、风管在穿过墙体或楼板处不得设置接口，风管沿墙体或楼板装置时，间隔墙面、楼板的间隔应大于150mm；
6. The air duct shall not be provided with an interface at the place where it passes through the wall or floor. When the air duct is installed along the wall or floor, the interval between the wall and floor shall be greater than 150 mm.
7、风阀的电动执行组织装置有必要可靠固定，禁止随意放置在风管上；
7. The electric actuating organization device of the wind valve must be reliable and fixed, and it is forbidden to be placed on the wind pipe at will.
8、手动密闭阀装置，阀门上标志的箭头方向有必要与受冲击波方向共同；
8. Manual closed valve device. The arrow direction on the valve must be in common with the direction of the shock wave.
9、现场风管接口的装备，不得缩小其有用截面；
9, the equipment of on-site wind pipe interface shall not reduce its useful cross section.
10、、空调风管支吊架应设不燃绝热垫防止产生冷桥，绝热垫应在支吊架制造时锚固在横担上；
10. Air-conditioning duct support and hanger should be equipped with non-combustible insulation cushion to prevent the cold bridge, insulation cushion should be anchored on the cross-bearing when the support and hanger are manufactured.
11、对体系风管的检测，宜选用分段检测、汇总剖析的办法。在严厉装置质量管理的基础上，体系风管的检测以总管和干管为主。当选用漏光法检测体系的严密性时，低压体系风管以每 10m 接缝，漏光点不大于 2 处，且100m 接缝均匀不大于 16处为合格；中压体系风管每 10m接缝，漏光点不大于 1 处，且 100m 接缝均匀不大于 8 处为合格。
11, for the detection of system air duct, we should choose the method of sectional detection and summary analysis. On the basis of strict quality control, the detection of system duct is mainly composed of main pipe and dry pipe. When the tightness of the system is checked by leak light method, the air duct of low pressure system is qualified with every 10 m joint, no more than 2 leak points, and no more than 16 100 m joints; the air duct of medium pressure system is qualified with every 10 m joint, no more than 1 leak point, and no more than 8 100 m joints.
三.制品维护措施
Three. Product maintenance measures
1、风管转移装卸应轻拿轻放，不得在地面上拖拽，并防止磕碰，摔绊；不得损坏法兰镀锌层，如有划伤应补漆完好；
1. Air pipes should be handled lightly, not dragged on the ground, and prevent knocking, tripping; not damage the galvanized flange coating, if scratched, should be repaired in good condition;
2、风管吊装过程中，两头未衔接处有必要用塑料薄膜封住，风管上风口装置前相同需用塑料薄膜封住，透明胶带粘贴好，以防尘埃进入；
2. In the process of hoisting air duct, it is necessary to use plastic film to seal the non-junction between the two ends. The same plastic film should be used to seal the air duct outlet before the installation. Transparent tape should be pasted well to prevent dust from entering.
3、关于穿越设备管理用房风管，穿墙部位距墙500mm以内有必要用塑料薄膜做好维护，以防土建施工单位灰料污染风管；
3. It is necessary to use plastic film to maintain the air duct of the room for the management of crossing equipment within 500 mm from the wall so as to prevent the air duct from being polluted by ash materials of civil construction units.
4、装置好的风管上面禁止堆放杂物或站在上面施工。
4, a good wind pipe is not allowed to pile up debris or stand on it.
