不同类型的净化器其内部构造也不同

发布时间:2017/06/05

1、能充分地极化。在丝板结构中,我们可以根据需要随意增减丝的极数,达到最佳的极化效果。多层丝使电场相对均匀,而且无死角。
1, it can be polarized sufficiently. In the wire plate structure, we can arbitrarily increase the number of wires according to the requirements to achieve the best polarization effect. The multilayer filament makes the electric field relatively uniform and has no dead ends.
2、阻力小。由于丝板内的结构是左右对称的,所产生的电场风是四散的,成为内应力而相互抵消了。
2, small resistance. Because the structure inside the wire plate is symmetrical, the electric field wind generated is dispersed and becomes internal stress and counteracts each other.
3、吸附区可达到最佳点。由于该区所用的电源是独立的,又无需考虑其它(如极化等),所以可调出最佳的电场强度。
济南通风管道工程
3, the adsorption zone can reach the best point. Since the power used in this area is independent, there is no need to consider other (such as polarization), so the optimum electric field strength can be brought out.
4、无效区间小。丝板和板板间的间隔可以做得很小,提高空间的有效利用率。但缺点是丝板的结构和生产工装较为复杂,丝的选材不好就会造成断丝。有些厂家用板在它的边缘做成波浪型或锯齿型来代替,虽然效果差点,但克服了丝易断的缺点。
4, invalid interval is small. The spacing between the plate and the plate can be made very small and the effective utilization of space is improved. But the disadvantage is that the structure of the silk board and the production tooling are more complex, and the material selection of the silk is bad, it will lead to broken wires. Some manufacturers use plates at their edges to make waves or zigzag instead of, although the effect is almost, but overcome the shortcomings of silk break easily.
综上所述,一个好的高压净化器的电极栅结构应该能充分极化和充分收集,并且极化和收集要分开。 为了提高净化率应尽量多设几级(层)。
To sum up, the electrode grid structure of a good high voltage purifier should be sufficiently polarized and fully collected, and polarization and collection should be separated. In order to improve the purification rate, as many layers as possible.
